openECSC 2025¶
Challenge: Calamansi¶
Tags: stego¶
Difficulty: Medium¶
Table of Contents¶
Solution Overview¶
The provided calamansi.png appears to be a simple flat calamansi-yellow square, but it's actually an APNG (animated PNG) with 50 hidden frames. Each frame contains letter-shaped differences in the RGB channels that are invisible due to transparent alpha channels. By parsing the PNG chunk structure, extracting and decompressing each frame's raw pixel data, converting non-background pixels to white, and concatenating the resulting character images, the complete flag is revealed as a horizontal strip.
Tools Used¶
- Python 3 standard library (
struct,zlib,itertools) - Pillow (PIL) for image processing and manipulation
filecommand for initial format verification
Solution¶
When I first looked at this challenge, I was immediately suspicious. The image looked like a simple flat yellow square, but the file size was 22 KB.
First thought: "Why would a solid color square be 22 KB? That's way too big for what should be a tiny PNG."
Initial Investigation¶
I ran a quick check on the file format:
Hmm, that didn't show anything special. But then I tried:
Still no indication of animation. But that file size kept bothering me. Let me try a more detailed check:
BINGO! The verbose output revealed something crucial:
- The PNG had fcTL (frame control) and fdAT (frame data) chunks
- These are APNG chunks - this was an animated PNG!
- There were 50 animation frames hidden in the file
Key insight: "The file is an APNG with 50 frames. Each frame might contain part of the flag, but why can't I see the animation?"
Understanding the APNG Structure¶
I decided to parse the PNG manually to understand its structure. APNGs work by having:
- An IDAT chunk for the default/first frame
- fcTL chunks that control frame timing/blending
- fdAT chunks containing the actual frame data
My approach became: extract every fdAT chunk, decompress the frame data, and see what's actually in each frame.
import struct, zlib
from pathlib import Path
from PIL import Image
PNG_SIG = b"\x89PNG\r\n\x1a\n"
BG = (252, 255, 164) # The calamansi yellow background
with open("calamansi.png", "rb") as f:
assert f.read(8) == PNG_SIG
width = height = None
frames = []
while True:
header = f.read(8)
if not header:
break
length, chunk_type = struct.unpack(">I4s", header)
payload = f.read(length)
f.read(4) # Skip CRC
if chunk_type == b"IHDR":
width, height, *_ = struct.unpack(">IIBBBBB", payload)
print(f"Image dimensions: {width}x{height}")
elif chunk_type == b"fdAT":
# fdAT format: [4 bytes sequence] [compressed data]
frames.append(zlib.decompress(payload[4:]))
print(f"Found {len(frames)} animation frames")
Result: 50 frames extracted! But when I looked at the first few frames, I noticed something strange.
The Hidden Characters¶
Each decompressed frame contained raw RGBA pixel data. The PNG format stores pixels row by row, with each row having a filter byte followed by the actual pixel data.
The revelation came when I examined the pixel values:
stride = 1 + width * 4 # Filter byte + RGBA pixels
for i, raw in enumerate(frames[:3], start=1):
print(f"\nFrame {i}:")
different_pixels = 0
for y in range(height):
line = raw[y * stride : (y + 1) * stride]
assert line[0] == 0 # Filter type 0 (no filtering)
row = line[1:]
for x in range(width):
r, g, b, a = row[x * 4 : x * 4 + 4]
if (r, g, b) != BG: # Not background color
different_pixels += 1
if different_pixels <= 5: # Show first few
print(f" Pixel at ({x},{y}): RGB=({r},{g},{b}), Alpha={a}")
print(f" Total non-background pixels: {different_pixels}")
The breakthrough: - Most pixels were the background color (252, 255, 164) - But some pixels had different RGB values (usually white: 255, 255, 255) - However, ALL pixels had alpha = 0 (completely transparent)! - The different RGB pixels formed letter-like shapes
This explained everything! The animation frames contained letters, but they were invisible because the alpha channel made them transparent.
Revealing the Characters¶
"If the frames contain letter-shaped RGB differences but they're invisible due to alpha, I just need to make them visible by ignoring the alpha channel."
My solution: For each frame, convert every non-background pixel to white (255) and every background pixel to black (0), creating a binary image that reveals the hidden character.
for i, raw in enumerate(frames, start=1):
out = Image.new("L", (width, height), 0) # Grayscale image, black background
pixels = out.load()
for y in range(height):
line = raw[y * stride : (y + 1) * stride]
row = line[1:] # Skip filter byte
for x in range(width):
r, g, b, a = row[x * 4 : x * 4 + 4]
if (r, g, b) != BG: # Non-background pixel
pixels[x, y] = 255 # Make it white
# Background pixels stay black (0)
out.save(f"revealed_{i:02d}.png")
Success! Each revealed_XX.png file now showed a single character clearly visible as white text on a black background.
Assembling the Flag¶
After extracting all 50 character images, I needed to combine them into the final flag.
The final insight: "The characters are already in the right order - the frame numbers correspond to the flag character positions."
I concatenated all the revealed character images horizontally:
def stitch_frames():
frames = []
for i in range(1, 51): # 50 frames
img = Image.open(f"revealed_{i:02d}.png").convert("L")
frames.append(img)
# Calculate total width
total_width = sum(frame.width for frame in frames)
max_height = max(frame.height for frame in frames)
# Create canvas and paste each frame
canvas = Image.new("L", (total_width, max_height), 0)
x_offset = 0
for frame in frames:
canvas.paste(frame, (x_offset, 0))
x_offset += frame.width
canvas.save("flag.png")
Opening flag.png revealed the complete flag as a horizontal strip of 50 characters!
Solution Scripts¶
Extract and reveal characters per frame:
import struct, zlib
from pathlib import Path
from PIL import Image
PNG_SIG = b"\x89PNG\r\n\x1a\n"
BG = (252, 255, 164)
with open("calamansi.png", "rb") as f:
assert f.read(8) == PNG_SIG
width = height = None
frames = []
while True:
header = f.read(8)
if not header:
break
length, chunk_type = struct.unpack(">I4s", header)
payload = f.read(length)
f.read(4) # CRC
if chunk_type == b"IHDR":
width, height, *_ = struct.unpack(">IIBBBBB", payload)
elif chunk_type == b"fdAT":
frames.append(zlib.decompress(payload[4:]))
Path(".").mkdir(exist_ok=True)
stride = 1 + width * 4
for i, raw in enumerate(frames, start=1):
out = Image.new("L", (width, height), 0)
pixels = out.load()
for y in range(height):
line = raw[y * stride : (y + 1) * stride]
assert line[0] == 0 # filter type 0
row = line[1:]
for x in range(width):
r, g, b, a = row[x * 4 : x * 4 + 4]
if (r, g, b) != BG:
pixels[x, y] = 255
out.save(f"revealed_{i:02d}.png")
Concatenate revealed frames:
#!/usr/bin/env python3
import glob
import os
import re
from typing import List, Tuple
from PIL import Image
Frame = Tuple[int, Image.Image, str]
def load_frames(pattern: str = "revealed_*.png") -> List[Frame]:
frames: List[Frame] = []
for path in sorted(glob.glob(pattern)):
match = re.search(r"(\d+)", os.path.basename(path))
idx = int(match.group(1)) if match else -1
frames.append((idx, Image.open(path).convert("L"), path))
frames.sort(key=lambda item: item[0])
return frames
def stitch(frames: List[Frame]) -> Image.Image:
total_width = sum(frame.width for _, frame, _ in frames)
max_height = max(frame.height for _, frame, _ in frames)
canvas = Image.new("L", (total_width, max_height), 0)
x = 0
for _, image, _ in frames:
canvas.paste(image, (x, 0))
x += image.width
return canvas
def main() -> None:
frames = load_frames()
order = " ".join(os.path.basename(path) for _, _, path in frames)
print("Using frames in left-to-right order:\n", order)
stitched = stitch(frames)
stitched.save("flag.png")
if __name__ == "__main__":
main()
Running these two scripts produces flag.png, a 50-character strip that spells out the answer.
Flag¶
openECSC{B3f0r3-1t-w45-Y3ll0w-n0w-1t5-c4l4m4n51}
